1/4 x 5 Countersunk Phillips Flat Head Blue Concrete Screw Anchors (100 pcs Screw Kit) with one Screwdriver and Drill Bit for Concrete, Masonry, Block, Brick and Wood Fastening
Product details
| Management number | 211239135 | Release Date | 2026/04/04 | List Price | $21.56 | Model Number | 211239135 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- [PRODUCT] Includes 100 1/4 inch [8/32"] (#14 screw) x 5 inch long Screw Anchors, 1 Drill Bit & 1 Screwdriver Bit so you are ready to tackle your Commercial, DIY & Home improvement jobs - Heavy Duty General Purpose Versatile Fixing Screws
- [APPLICATIONS] Concrete Screws can be used for Applications including Concrete Block, Cinder Block, Mortar, Masonry, Brick, Wood, Drywall & Stucco
- [HIGH QUALITY] A High and Low Thread Design along with Wide Serrated Threads provides a Faster Drilling Speed allowing the Screw Anchor to Quickly Penetrate any Base Material
- [SELF-TAPPING TECHNOLOGY] A Diamond Point Designed Screw Tip Threads Directly into Base Materials, Eliminating the need for other Anchors or Screws
- [CORRSOION RESISTANT] A Blue Epoxy Coating can Withstand Hydrochloric Acid Corrosion for 1,000 Hours, Ensuring Long Lasting Durability. Anti-Corrosion Coating is especially useful in Hurricane or Damp Environments
- [MATERIAL] Manufactured from Heat-Treated 1022A High Strength Carbon Steel for Strength and Durability
- [SERVICE] 100% Customer Satisfaction and Money Back Guarantee & Responsive Customer Support for Returns. Please visit our website for further technical information and to learn about the FixMaster offering https://www.myfixmaster.com/
- The Head style is Countersunk Phillips Flat - This will allow the fastener head to lay flush in the base material. The Diameter is 1/4", The Overall Length is 5", The Thread Length is 3.33", The Total number of Threads is 23. [Setting Driver Required & included with each box of Anchors] FOR 1/4" - a 5/16" nut driver is required for driving the anchor into the base material. FOR 1/4" - Each Tapcon style Blue Screw requires a 3/16" hole to be drilled in the base material being used (Concrete, Block, Brick & Wood). The hole should be drilled with the carbide tipped bit that is included in each box of anchors.
- [Minimum Embedment] The Minimum Anchor embedment into the Base Material is 1". This means the Anchor must be installed so that a minimum of 1" of the anchor is embedded into the Base Material. [Fixture Hole Diameter] FOR 1/4" - The hole in the Fixture or Base Material being Fastened must be Larger than the designated diameter of the anchor. The 1/4" diameter anchor requires the hole in the fixture to be 5/16".
- [Spacing between Anchors] Each anchor must be spaced a Minimum Distance of 4" from each other Anchor when measured center to center. [Edge Distance] FOR 1/4" - Each anchor Cannot be installed any closer than 3" from an unsupported edge of the concrete. [Maximum Fixture Thickness] The Maximum Fixture Thickness or the Maximum Thickness of the Material being Fastened for a anchor is 3.5" to 4". This will ensure that the Minimum Embedment of 1" will be met
| Brand | FixMaster |
|---|---|
| Color | Blue |
| Model | CSF145-100 |
| Head Type | Flat |
| Size Name | 1/4 x 5 |
| Metal Type | Carbon Steel |
| Unit Count | 100.0 Count |
| Part Number | CSF |
| Thread Size | See Product Details |
| Thread Type | Coarse, Right Hand |
| Drive System | Phillips and Slotted |
| Finish Types | Blue Epoxy Coated |
| Grade Rating | Premium |
| Manufacturer | FixMaster |
| Thread Class | standard |
| Thread Style | Right Hand |
| Fastener Size | No. 14 |
| Fastener Type | Screw |
| Item Diameter | 0.25 Inches |
| Material Type | Carbon Steel |
| Exterior Finish | Ruspert Anti-Corrosion Coating |
| Item Dimensions | 5 x 0.25 x 5 inches |
| Thread Coverage | Partially Threaded |
| Number of Pieces | 100 |
| Screw Head Style | Flat |
| Screw Point Style | Diamond Point |
| Compatible Groove Diameter | 0.19 Inches |
| Global Trade Identification Number | 00850059746141 |
